W330B

The features of Raching oak wine barrel:

Whirlpool Embraco refrigeration compressor imported from United States

Import natural high-quality cherry /oak solid wood for unique design cabinet

Computer intelligent temperature control

5 times longer service life than normal refrigerator

Big capacity storage with double-layer tempered glass door

Inquire Now Next Product

Product Details

Introduction

· 1. The Whirlpool Embraco refrigeration compressor imported from United States, specially designed for thermostatic wine cooler ;
· 2. The imported natural high-quality cherry /oak solid wood for unique design cabinet;
· 3. Environmental protection paint coating effect with different colors;
· 4. The unique patent removable refrigeration unit temperature control mode, easy to installation, convenient dis-assembly and maintenance
· 5. Computer intelligent temperature control , the whole ambient temperature is between 6 to 18 ℃ ;
· 6. The innovation of refrigeration air supply system is placed on the top of the wine cabinet. The cold air flows from the top of the cabinet to the bottom of the cabinet.
· 7.Activated carbon device to remove peculiar smell and ventilated convection hole to avoid peculiar smell remaining in the cabinet;
· 8. Backlit LCD touch display screen with creative wine glass pattern display;
· 9. "Dry and wet separation" technology between the cabinet and the refrigeration system, no frost or condensation water leave in the cabinet;
· 10. Door body deformation prevention design, door body make with solid wood material embedded with aluminum alloy keel and insulation cotton, to avoid the temperature differenceand deform problems of common solid wood door ;
· 11. Fashion and simple design frameless double-layer tempered glass door with dark browncolor and anti-ultraviolet design;
· 12. Each wine cabinet is equipped with four display modes of wine racks:lay flat, reclining, layering and draw out;
· 13.The special colored decorative for the liner in the industry and breaks through the tradition of ABS liner. 14. Imported beech Solid wood from Europe for the racks, buffing by hand without paint, food-grade wine storage environment control;
· 15. All-copper tube refrigeration system, strong corrosion resistance, 5 times longer service lifethan normal refrigerator;
· 16. The wine cabinet shall be equipped with security lock.

Main features
Wood colour of cabinet	Red/Brown/Black
Cabinet Type	Standing alone
Model	W330B
Brand	RACHING
Product Name	Wine cooler
Warranty	1 year
Dimensions	H1620xW600xD610mm
Function(s)	Maturing
Door details	Tempered dark brown glass door
Door opening direction	Right or left
Capacity	100bottles(750ml)
Type of interior lighting	LED
The Quantity of shelves	fixed shelf*10
Internal lighting	Yes
Compressor brand	USA Embraco
Recommended ambient temperature range	Upper 5-12°C Under12-22°C
Can be fitted	No
Temperature display type	Backlit LCD touch screen
Humidity Filter	Yes
Humidity measurement	Yes
Temperature setting range	5°-22°C
The temperature control mode	Computer temperature control
Lock	Yes
Humidity display	Yes
External covering	Oak/cherry wood
Coolant	R134A
Shipment specifications
Gross weight	100kg
Net weight	85kg
Package size	H1840D720W720mm
Container volume	20’container=24units 40’container=48units
